Product Description

The code system is : type + tube outerdia& Innerdia + color

1. Type

EN	Nylon
EU	Polyurethane (PU)

2. Tube outerdia& innerdia

Code	0425	0640	0850	0860	1065	1280	1613
OD(mm)	Φ4.0	Φ6.0	Φ8.0	Φ8.0	Φ10.0	Φ12.0	Φ16.0
ID(mm)	Φ2.5	Φ4.0	Φ5.0	Φ6.0	Φ6.5	Φ8.0	Φ13.0

3. Color

C	B	BU	R	Y	G	W	O
transparent	black	blue	red	yellow	green	white	orange

4. Product pictures

PU PIPE(1) PU PIPE(2) PU PIPE(3) PU PIPE(4)

Features--why is this unique?

*Resistance in high pressure, shock, corruption, deterioration, extrem climate and bent.

(Seen from technical data)

Hardness	90±2A
Density	1.24±0.02g/mm
Resistance to tension	550kg/cm²
Extension ratio	450%
Tear intensity	10kg/mm
Wear and tear	35mm²
Suitable temperature	-50~100℃ (-58~212℉)
Acid& alkaling-resisting degree	±14PH
Withstand atmospheric pressure	0.8Mpa(8.2kgf/cm²)

* High precision of inside and outside diameter.

It can be choosed by your preference.

* Suitable for distribute tube and various connectors.

Multichoices are available.

Product Presentation

PU PIPE

specification

PU Tube Pneumatic Tube Pipe High Pressure Flexible Nylon PU Air Hose Pneumatic pipe Nylon Pneumatic Tube Pipe

If you have any enquiry about quotation or cooperation,please feel free to email us at sale@yingselectric.com or use the following enquiry form. Our sales representative will contact you within 24 hours. Thank you for your interest in our products.
