YUMO G50-3A30NC NPN NO+NC Output 50cm Long detection distance DC Diffuse Photoelectric Switch Sensor

Application: Detection of thick carton; Check whether the beer bottle is labeled or not; Product accounting; Detection of broken strips in carding machine; Check out the broken or faulted tobacco rolling paper; Invasion Prevention of Forbidden Zone.
  • G50-3A30NC
  • YUMO
  • 1
Availability:

YUMO G50-3A30NC NPN NO+NC Output 50cm Long detection distance DC Diffuse Photoelectric Switch Sensor


CODE G50
Detection distance 30-50cm
Diffuse Type 10-30
VDC
NPN NO G50-3A30NA
NC G50-3A30NB
NO+NC G50-3A30NC
PNP NO G50-3A30PA
90-250
VAC
NC G50-3A30PB
NO+NC G50-3A30PC
SCR
controllable
 silicon
NO
NC
Relay output G50-2A30JC
Detection distance 4M
Retroreflictive 10-30
VDC
NPN NO G50-3B4NA
NC G50-3B4NB
NO+NC G50-3B4NC
PNP NO G50-3B4PA
90-250
VAC
NC G50-3B4PB
NO+NC G50-3B4PC
SCR
controllable
 silicon
NO
NC
Relay output G50-2B4JC
Detection distance 5M
Trough beam 10-30
VDC
NPN NO G50-3C5NA
NC G50-3C5NB
NO+NC G50-3C5NC
PNP NO G50-3C5PA
90-250
VAC
NC G50-3C5PB
NO+NC G50-3C5PC
SCR
controllable
 silicon
NO G50-2C5LA
NC
Relay output G50-2C5JC
DC/SCR Control output DC:200mA AC:300mA relay:2A
DC/AC Consumption current DC<15 mA  AC<10 mA
DC/AC Response time DC<2ms  AC<20ms
Directional angle 3°-10°
Detected object transparent or opaque body
WoJrking envlrOnment temDerature -25ºC~+55ºC
Intensity ofillumination of working environment Sunlight under 10000LX incandescent lamp under 3000LX
Shell materia Plastic
Protection grade IP54
G50-3A30NC (4) G50-3A30NC (5) G50-3A30NC (6)

Overall dimensions:  (unit:mm)

 G50
