G14-3A10NC Diffused Reflection Type NO+NC Output Photoelectric Switch

The mechanical quantity to be measured, such as displacement, pressure change into an electrical capacitance sensor. Therefore, capacitive sensors can be divided into pole pitch change type, area change type, change the media type categories. Pole pitch change type is generally used to measure the tiny lines or due to force displacement, pressure, vibration caused by the pole pitch changes (see capacitive pressure sensor). Area change type is generally used to measure the angular displacement or larger linear displacement. Change media type commonly used in level measurement and a variety of medium temperature, density determination and humidity.
  • G14-3A10NC

  • YUMO

  • YM0000647

  • 20

Availability:

G14-3A10NC Diffused reflection Type  NO+NC output Photoelectric switch

Diffuse Type

Diffuse reflection type photoelectric switch integrates the transmitter and the reciver. Light reflected by the photoelectric switch is reflected back to the receiver by the detected object.


Electrical Datasheet

Outward appearance illustration G14
Overall dimensions YUMO sensor catalouge-31
Diffuse type Detection distance 10cm
10-30VDC NPN NO G14-3A10NA
NC G14-3A10NB
NO+NC G14-3A10NC
PNP NO G14-3A07PA
90-250VAC NC G14-3A07PB
NO+NC G14-3A07PC
Retroreflective type Detection distance 1m
10-30VDC NPN NO G14-3B1NA
NC G14-3B1NB
NO+NC G14-3B1NC
PNP NO G14-3B1PA
90-250VAC NC G14-3B1PB
NO+NC G14-3B1PC
Through beam Detection distance 3m
10-30VDC NPN NO G14-3C3NA
NC G14-3C3NB
NO+NC G14-3C3NC
PNP NO G14-3C3PA
90-250VAC NC G14-3C3PB
NO+NC G14-3C3PC
DC/SCR Control output DC:200mA
DC/AC Consumption current DC<15mA
DC/AC Response time Dc<2ms
Directional angle 3° -10°
Detected object transparent or opaque body
Working environment temperature -25ºC~+55ºC
Intensity of illumination of working environment Sunlight under 1000LX incandescent lamp under 3000LX
Shell material Plastic
Protection grade IP54

G14-3A10NC (4)G14-3A10NC (3)G14-3A10NC (7)G14-3A10NC (6)G14-3A10NC (8)
