Plastic Cylindrical Photoelectric Electronic Sensor Switch

The mechanical quantity to be measured, such as displacement, pressure change into an electrical capacitance sensor. Therefore, capacitive sensors can be divided into pole pitch change type, area change type, change the media type categories. Pole pitch change type is generally used to measure the tiny lines or due to force displacement, pressure, vibration caused by the pole pitch changes (see capacitive pressure sensor). Area change type is generally used to measure the angular displacement or larger linear displacement. Change media type commonly used in level measurement and a variety of medium temperature, density determination and humidity.
  • G18-3A10PC

  • YUMO

  • YM0000651

  • 20

Availability:

Plastic cylindrical photoelectric electronic sensor switch

Model NO. G18-3A10PC
Working voltage 90-250VAC
Output form PNP
Output state NO+NC
Detection way diffused reflection type (scattered reflection type)
Housing Material Plastic
Protection grade IP54
Detection distance 10cm

G18 series Photoelectric Sensor switch

Code G18
Overall dimensions YUMO sensor catalouge-31
Diffuse type Detection distance 10-30cm
10-30VDC NPN NO G18-3A10NA
NC G18-3A10NB
NO+NC G18-3A10NC
PNP NO G18-3A10PA
90-250VAC NC G18-3A10PB
NO+NC G18-3A10PC

  SCR

Contro Hable

silicon

NO G18-2B10LA
NC G18-2B10LB
Retroreflective type Detection distance 2m
10-30VDC NPN NO G18-3B2NA
NC G18-3B2NB
NO+NC G18-3B2NC
PNP NO G18-3B2PA
90-250VAC  NC G18-3B2PB
NO+NC G18-3B2PC
  SCR

Contro Hable

silicon

NO G18-2B2LA
NC G18-2B2LB
Through beam Detection distance 5m
10-30VDC NPN NO G18-3C5NA
NC G18-3C5NB
NO+NC G18-3C5NC
PNP NO G18-3C5PA
90-250VAC  NC G18-3C5PB
NO+NC G18-3C5PC

SCR

Contro Hable silicon

NO G18-2B5LA
NC G18-2B5LB
DC/SCR Control output DC:200mA AC:300mA
DC/AC Consumption current DC<15mA AC:<10mA
DC/AC Response time Dc<2ms AC<2mS
Directional angle 3°-10°
Detected object transparent or opaque body
Working environment temperature -25~+55ºC
Shell material Plastic or Metal
Protection grade IP54~IP67

G18-3A10PC (6) G18-3A10PC (1)G18-3A10PC (4)G18-3A10PC (5)
