Product Description

OVERALL DIMENSIONS
D i f f u s e T y p e		Detection distance		10cm
	10- 10 VDC	NPN	NO	G64-3A10NA
			NC	G64-3A10NB
			NO+NC	G64-3A10NC
		PNP	NO	G64-3A10PA
	90～ 250 VAC		NC	G64-3A10PB
			NO+NC	G64-3A10PC
		SCR ControHable silicon	NO
			NC
		Relay output
R e t r o r e f l i c t i v e		Detection distance		1.5m-2m
	10- 10 VDC	NPN	NO	G64-3B2NA
			NC	G64-3B2NB
			NO+NC	G64-3B2NC
		PNP	NO	G64-3B2PA
	90～ 250 VAC		NC	G64-3B2PB
			NO+NC	G64-3B2PC
		SCR ControHable silicon	NO
			NC
		Relay output
T r o u g h b e a m		Detection distance		3m
	10- 10 VDC	NPN	NO	G64-3C3NA
			NC	G64-3C3NB
			NO+NC	G64-3C3NC
		PNP	NO	G64-3C3PA
	90～ 250 VAC		NC	G64-3C3PB
			NO+NC	G64-3C3PC
		SCR ControHable silicon	NO
			NC
		Relay output
DC/SCR／Control output				DC:200mA、AC：300mA
DC/AC Consumption current				DC<15mA、AC:<10mA
DC/AC Response time				Dc<2ms、AC<20ms
Directional angle				3。-10。
Detected object				transparent or opaque body
Working environment temperature				-25℃～+55℃
Intensity ofillumination ofworking environment				incandescentlamp under 1000LX
Shell materia				Plastic
Protection grade				IP66

photoelectric switch Photoelectric Switch Sensor Infrared ray sensor photoelectric sensor G64 Sensor
