19mm Red Power Symbol Push Button Switch

  • ABS19S-P11-C-G-24VDC
  • YUMO
Availability:

19mm Red Power symbol  push button switch

ABS

Size

Material

Head type

Switch combination

Work type

Lamp type

Lamp color

Lamp voltage

Metal Switch

06mm

08mm

12mm

16mm

19mm

22mm

25mm

C:Chromium plated brass

A:Zinc alloy plated chromium

S:Stainless steel

P:Plastics

P:flat

G:High

Q:Ball

M:Mushroom

11:1NO1NC

22:2NO2NC

1:1NO/1NC (Welding)

10:2NO2NC(Welding)

0:1NO/1NC (terminal)

00:2NO2NC(terminal)

Z:Maintained
       :Momentary

D:Center point

E:Ring lamp

C:Power mark

T:Custom patterm

R:Red

G:Green

Y:Yellow

B:Blue

W:White

AC/DC

3V
6V
12V
24V
36V
48V
110V
120V

Switching Operation

Type

Diagram

sign

Explanation

1NO



Double breakpoint slow moving contact switch with two terminals

1NO 1NC



Single breakpoint snap change contact switch with three terminals

1NO 1NC



Double breakpoint snap change contact switch with four terminals

Switching Operation

Rated insulation Voltage

250

Heating current Ith

Temperature does not exceed the maximum allowed current

Rated voltage

12V

24V

110V

220V

Rated
 current

AC
 50/60Hz

Resistive load

-

-

5A

3A

Inductive load

-

-

3A

2A

DC

Inductive load

5A

5A

1A

0.5A

Inductive load

2A

2A

0.2A

0.1A

Contact material

Silver Plated Gold

Lamp Ratings

Lamp Type

LED lamp(AC/DC)

Rated Voltage

3V,6V,12V,24V,36V,110V,220V AC/DC

Rated Current

About 15mA

LED Color

G O W P

Life

40000hours
