RK01-2-2-4|RK01-2-3-4 M8 right angle sensor connector

Sensor connector commonly used are M12 connector, M8 connector, solenoid valve connector. M12 connector is M12 * 1, the connection is screw connection, the enclosure protection class IP67, with cable and cable without cable, cable optional PVC (ordinary) or PUR (oil wear) material, cable length The cable is M8 * 1, the connection is screw connection, protection class IP67, with cable and cable without cable, optional PVC (ordinary) or PUR (oil and wear) materials, cable Length can be customized according to user requirements; solenoid valve connector locking method for the center of the screw, the connection for the screw, the enclosure protection class IP65.Connectors are widely used in sensors, detection equipment, electronic instrumentation, electronic machinery, communications, aviation, navigation, computers, LED, automotive, engineering machinery.
  • RK01-2-2-4|RK01-2-3-4

  • YUMO

  • YM0000000058

Availability:

RK01-2-2-4|RK01-2-3-4  M8 right angle sensor connector

CONTACT VIEW

RK01-2-2-4RK01-2-3-4 M8 right angle sensor connector


APPLICATION





DC
AC
NO/NC

NPN/PNP
NO/NC

DC
AC
NO/NC

NPN/PNP
NO/NC

DC
AC
NO

NPN/PNP
NO/NC

DC
AC
NO/NC

Connector


Skin color

   black

Coupling nut material

   Cuzn,nickel plated

Over-current value [A]

   4.0

Rated voltage[V]

   250

Wire Length

   2m

Cable jacket material

   PVC



output display [LED]


bn,bu,bk
3x0.5

bn,bu
2x0.5

Black bn,bu
2X0.51

bn,bu,bk.wh
4x0.34

power indicator

   1

common data

  ━━

insulation resistance

 ≥-109Ω

envronment temperature scope[℃]

 -25-+80

environment temperature scope[℃]

 -25-+80

(DIN 40 050) protection level

  lP67

Capacitance

  250VAC/300VDC,Gr.C
