JS19H-10
YUMO
1
China
Our high strength anti-vandal metal push button switches and the indicator lamps are not only elegant appearance ,graceful, but also complete range of articles, variety of specifications, multipurpose, can meet various customers requirements in different fields, are widely applied in the key horizon control system of electromechanical instrument in various industry cabinet, household appliances and so on .
For your convenient selecting our products ,in the right page’s icon brief listed the drawing and the page number , the product introduction with details like model, the panel mounting dimensions, the electronic structure, the electrical specifications as well as the related parameters can be found according to the related page .
Specification | JS19H-10/ | |
The Front Shape | High Round | |
Terminal Type | Screw Termlnals | |
Switching | No.1 | |
Max.Switch Rating | 2A/36VDC | |
Contact Resistance | ≤50MΩ | |
Insulating Resistance | ≥1000MΩ | |
Dielectric Strengh | 2000VAC | |
Operating Temp | -20℃~+55℃ | |
Mechanical life | 1,000,000 cycles | |
Elctrical life | 200,000 cycles | |
Elctrical life | 1~6mm | |
Tortque | 5~14Nm | |
Operation Pressure | About4N | |
Operation Distance | About1.5mm | |
IP Degree | IP65 | |
Material | Contrct | Silver Alloy |
Button | Stanless Steel | |
Body | Stanless Steel(Nickel Plated Gold Plated) | |
Base | PBT | |
