SP-24AL 100-240VAC 24 DC input,Switching power supply uninterrupted power supply extended module PLC

100-240VAC 24 AC input,extended module PLC

  • SP-24AL
  • YUMO
  • YM00000016


SP series industrial switching power supply is especially designed for industrial equipment, which employ 35mm DIN guideway, with low ripple, wide range of input voltage from AC 100-240VAC,and can output DC5V,12V,24V, 48V.It provides UPS uninterrupted power supply and soft start. Remote controlling function is also provided with.


Performance & Features:

Internal-Installed EMI filter condenser
Input frequency: 47-63HZ
Output voltage stability:+-0.5%
Can be used for DIN installation (EN50022-35)
All range voltage input (85-264VAC,120V-370VDC)
Output voltage inching range (-5%~+10%,adjusting potentiometer V)
Have the function of soft-start (to limit the peak current of start and the pressure of the voltage to the components)
The current of the load can be roughly adjusted (means the maximum protective current of the load, adjusting potentiometer A)
Have the short circuit and over-load protection. (Over-load protection: 105%-135%)
nsulation and voltage endurance: >1.5KV
Power supply output with the LED indicator
  • Ripple:<100mVp-p
  • Efficiency: >80%
  • Remote control function. (the remote control switch can control having and not having the output voltage)
  • UPS function (External-connected battery can be charged when the AC power is supplied, the power supply will act as UPS when the AC power is off and the battery was connected.)
Over-heat protection function (The main control CMOS chip stops output when the temperature is beyond 135 degree and the output will renew automatically when the temperature drops to certain level.)



Technical Index:
ype
SP-05AS
SP-12AS
SP-24AS
SP-05AL
SP-12AL
SP-24AL
Voltage (V)
5
12
24
5
12
24
Current (A)
7
3
1.5
14
6
3
Dimensions (WXHXD)
71mm * 106mm * 65mm
126mm * 106mm * 65mm
Input Voltage
85-265VAC
Supply frequency
47-63Hz
Output voltage tolerance
1%
Max. Ripple/Noise
<100mVpp
Operation Temperature
-25 to 70
Efficiency
>80%
Installation Dimensions & Wiring Diagram:


plc controller

The switch power supply, with compact size, light weight (250G) and high efficiency, whose voltage and current can be matched, has current protection and provides with UPS support, soft start and remote control functions. It is widely used in computers, terminal equipments, communication equipment and almost all the electronic equipments. It is now a power
supply that electronics information industry cannot live without it.

Item Code Description
1 AF-10MR-A(with LCD) 85V-240VAC, 6 points AC input 4 points relay output
2 AF-10MR-A(without LCD) 85V-240VAC, 6 points AC input 4 points relay output
3 AF-10MR-D(with LCD) DC12/24V, 6points DC input 4 points (with analog input) relay output
4 AF-10MR-D(without LCD) DC12/24V, 6points DC input 4 points (with analog input) relay output
5 AF-10MR-E(with LCD) DC12/24V, 6 points DC input 4 points relay output
6 AF-10MR-E(without LCD) DC12/24V, 6 points DC input 4 points relay output
7 AF-10MT-D(with LCD) DC12/24V, 6points DC input 4 points transistor output(exuivalent NPN)
8 AF-10MT-D(without LCD) DC12/24V, 6points DC input 4 points transistor output(exuivalent NPN)
9 AF-10MT-GD(with LCD) DC12/24V, 6points DC input 4 points transistor output(exuivalent PNP)
10 AF-10MT-GD(without LCD) DC12/24V, 6points DC input 4 points transistor output(exuivalent PNP)
11 AF-10MT-E(with LCD) DC12/24V,6 points DC input 4 points electronic transistor output
12 AF-10MT-E(without LCD) DC12/24V,6 points DC input 4 points electronic transistor output
13 AF-20MR-A(with LCD) 85V-240VAC ,12 points AC input 8 points relay output
14 AF-20MR-A(without LCD) 85V-240VAC ,12 points AC input 8 points relay output
15 AF-20MR-D(with LCD) DC12/24V,12 points DC input 8 points (with analog input) relay output
16 AF-20MR-D(without LCD) DC12/24V,12 points DC input 8 points (with analog input) relay output
17 AF-20MR-E(with LCD) DC12/24V ,12 points DC input 8 points relay output (without analog input)
18 AF-20MR-E(without LCD) DC12/24V ,12 points DC input 8 points relay output (without analog input)
19 AF-20MT-E(with LCD) DC12/24V,12points DC input 8 points transistor output(exuivalent NPN)
20 AF-20MT-E(without LCD) DC12/24V,12points DC input 8 points transistor output(exuivalent NPN)
21 AF-20MT-D(with LCD) DC12/24V,12points DC input 8 points transistor output(exuivalent NPN)
22 AF-20MT-D(without LCD) DC12/24V,12points DC input 8 points transistor output(exuivalent NPN)
23 AF-20MT-GD(with LCD) DC12/24V,12points DC input 8 points transistor output(exuivalent PNP)
24 AF-20MT-GD(without LCD) DC12/24V,12points DC input 8 points transistor output(exuivalent PNP)
25 AF-C232    Cable for FAB and PC Modem for programming
26 AF-C485     Interface between 485bus and FAB for network monitor
27 AF-CMP   The cable connect to the telephone module port  "TO PC'
28 AF-COPY  Copy module
29 AF-D232  the cable connecting FAB and PC (frontispiece plug type)
30 AF-MUL-D Voice module to realize voice function(DC POWER)
31 AF-DUSB   the interface between FAB and PC USB port (frontispiece plug type)
32 AF-LCD  Removable LCD clip in screen for easy programming
33 AF-M232     Interface between FAB and MODEM for remote control and programming
34 AF-MUL Voice module to realize voice function(AC POWER)
35 AF-P485    Interface between 485bus and PC for network function
36 AF-S485 Interface is the connector between RS232 and RS485 (DIN installation).
37 AF(SR)-USB     USB/RS232 convertor (DIN installation)
38 SP-05AL Input: 110/220VAC Output: Voltage :5VDC   Current :14A Din rail type
39 SP-05AS Input: 110/220VAC Output: Voltage :5VDC   Current :7A Din rail type
40 SP-12AL Input: 110/220VAC Output: Voltage :12VDC   Current :6A Din rail type
41 SP-12AS Input: 110/220VAC Output: Voltage :12VDC   Current :3A Din rail type
42 SP-24AL Input: 110/220VAC Output: Voltage :24VDC  Current :3A Din rail type
43 SP-24AS Input: 110/220VAC Output: Voltage :24VDC   Current :1.5A Din rail type
44 SR-12MRAC 100-240VAC 8 Points AC input, 4 points relay output
45 SR-12MRDC DC12/24V 8 points DC input (with 6 points analog ) , 4 points relay output
46 SR-12MTDC DC12/24V 8 points DC input (with 6 points analog ) , 4 points transistor output(NPN)
47 SR-12MGDC DC12/24V 8 points DC input (with 6 points analog ) , 4 points transistor output(PNP)
48 SR-20ERA 100-240VAC 12  AC input, 8 points relay output, 20 points extended module
49 SR-20ERD DC12/24V 12 points DC input , 8 points relay output, 20 points extended module
50 SR-20ETD DC12/24V 12 points DC input , 8 points transistor output ,20 points extended module (NPN)
51 SR-20EGD DC12/24V 12 points DC input , 8 points transistor output ,20 points extended module (PNP)
52 SR-22MRAC 100-240VAC 14 Points AC input, 8points relay output
53 SR-22MRDC DC12/24V 14 points DC input (with 8 points analog ) , 8 points relay output
54 SR-22MTDC DC12/24V 14 points DC input (with 8 points analog ) , 8 points transistor output(NPN)
55 SR-22MGDC DC12/24V 14 points DC input (with 8 points analog ) , 8 points transistor output(PNP)
56 SR-AUD The recording microphone and the wires between the sound card and the SR-VPA/SR-VPD
57 SR-CP Programmable cable can edit,analog, monitor from PC to Super Relay
58 SR-EANT Long connecting antenna of SR-RCA and SR-RCD
59 SR-ECBA AC type, to remotely connect the machine and the extended module
60 SR-ECBD DC type, to remotely connect the machine and the extended module
61 SR-EHC Connection set of SR-HMI, remotely connect SR machine
and SR-HMI 1.5m cable
62 SR-HMI-B monitor operator panel
63 SR-LED simple LED panel
64 SR-RCA 100-240VAC remote control receiver module
65 SR-RCD DC12/24V remote control receiver module
66 SR-TC DC3V remote control emitter
67 SR-USB USB/RS232 convertor (DIN installation)
68 SR-DUSB   the interface between SR and PC USB port (frontispiece plug type)
69 SR-VPA 100-240VAC phone voice module
70 SR-VPD DC12/24V  phone voice module
71 SR-WRT Programming panel
72 SR-TP for connecting SR PLC with text panel SH-300
73 SR-MC MODBUS module
74 SR-MCA MODBUS module
75 SR-MCD MODBUS module
76 SH-300 4.3"STN - LCD Display screen DC12/24VA
77 AR1520  convert RS-232 signals into isolated RS-422 or RS-485
78 AR1520U    Convert USB to RS-232/422/485 terminal
79 AR1521    convert RS-232 signals into isolated RS-422 or RS-485
80 AR1521U     Convert USB to RS-232/422/485 terminal
81 C2400                 Timer,counter,frequency meter,tachometer
82 software PLC software CD
