Proximity switches are the most common solution for non-contact detection. And the inductive type is the widely used proximity switches, which is through the electromagnetic waves to detect the metal abject near the sensor detection surface. In application, this is a very simple technology to detect 1”~2” metal object. YUMO Electric offer different series proximity sensor, that included inductive, photoelectrical, capacitive and etc. YUMO Electric continues to improve the performance and quality, enabling the sensors in a world-class level . If you are searching for proximity switch, YUMO will be your best choice.
Main features of proximity switch sensor:
Compact volume
High precision of repeated location
Diversified exterior structures
Good performance of anti-interference
Many output forms
High on-off frequency
Wide voltage range
Dustproof, vibtation proof,waterproof and oil proof
With short-circuit protection and inverted connecting protection
Long service life
Application:
Model NO. | LMF4-3005PC |
Working voltage | 10-30VDC |
Output form | PNP |
Output state | NO+NC |
Outward appearance | Angular column type |
Shell Material | ABS Resin |
Protection grade | IP67 |
Detection distance | 5mm |
Detection type | Flush |
LMF4 series proximity switch sensor:
Detection distance: 5mm | ||||
Flush | DC | NPN | NO | LMF4-3005NA |
NC | LMF4-3005NB | |||
NO+NC | LMF4-3005NC | |||
PNP | NO | LMF4-3005PA | ||
NC | LMF4-3005PB | |||
NO+NC | LMF4-3005PC | |||
two wire | NO | LMF4-3005LA | ||
NC | LMF4-3005LB | |||
SCR | NO | |||
NC | ||||
NO+NC | ||||
Relay output | ||||
Flush | DC | NPN | NO | |
NC | ||||
NO+NC | ||||
PNP | NO | |||
NC | ||||
NO+NC | ||||
two wire | NO | |||
NC | ||||
SCR | NO | |||
NC | ||||
NO+NC | ||||
Relay output | ||||
Control output | DC | 200mA | ||
SCR/ Relay | 300mA/1A | |||
Output voltage dropDC/AC | NPN PNP<3V,two wre<3.9V | |||
Consumption current | DC<15mA,AC<10mA | |||
Standard detected object | 20X20X1(A3 iron) | |||
Repeated precision | 0.03 | |||
DC/AC | 300Hz | |||
Working environment temperature | -25ºC~+75ºC | |||
Insulation resistance | 50MΩ | |||
Shell material | ABS Resin | |||
Protection grade | IP67 |
